Craig Uyeda's Schwinn Stealth 1000

Owner

Craig Deafscooter Uyeda

Owner's Other EVs

Location

Reseda, California United States ^map

Vehicle

2006 Schwinn Stealth 1000

Perm Motor PMG 132 Permanent Magnet DC

Drivetrain

#35 Heavy Duty Chain

Deafscooter's Custom Made
72 Volts, 275 amps ( small package )

Batteries

Sanyo 4/3AF 4500 mAh, 72.00 Volt, Nickel-Metal Hydride
Sanyo NiMH Cell and custom made package

System Voltage

72 Volts

Charger

Off Board 72 Volts Deafscooter's Custom Made NiMH Charger Station Maximum charge is 86.5 Volts

Instrumentation

Power Cut off , throttle power

Top Speed

84 MPH (135 KPH)
Top speed on GPS record is 83.6 mph
CHP's Radar show 77.0 mph top speed
and wrote ticket for excess of the 55 mph

Acceleration

Not yet

Range

2 Miles ( 3 Kilometers)
During Road Test

EV Miles

Current:	17 Miles (27 Kilometers)
	As of 12/16/2007

Seating Capacity

1 adult (160 pound seated)

Curb Weight

167 Pounds (75 Kilograms)

Tires

12 Inches air-filled tires Special Tire ( 40 psi nitrogen )

Conversion Time

3 Weeks

Conversion Cost

No Say

One time top speed is 83.6 mph on GPS and I got Ticket from CHP for 77 mph !!

2006 Schwinn Stealth 1000“PMG-S.S.S-T1000”
