OwnerPete Temple
LocationFort Collins, Colorado United States map
Email email image
Vehicle1966 MG Midget
MotorWarfield Impulse 9 Series Wound DC
9" series wound dc motor
Drivetrain4 speed manual,no clutch
ControllerCafe Electric Zilla Z1
Batteries38 CALB/Skyenergy 100AH, 3.60 Volt, Lithium Iron Phosphate
8/6/09 BATTERIES ARE LEAVING CHINA NEXT WEEK

10/10/09 Batteries are here!
System Voltage120 Volts
ChargerElcon
Chinoz water proof PFC 8A

Charger is very simple to use and does a nice job charging the
batteries.
DC/DC ConverterIota DLS 45
BATTERY CHARGER FOR RV - ALSO WORKS AS A DC-DC
InstrumentationLaptop with Zilla Config running
Lithiumate lite BMS drives a standard fuel gauge for battery SOC
Top Speed90 MPH (144 KPH)
Have gone 90 MPH with more to go.
AccelerationUnder full acceleration this car will spin the tires in second gear.
Never had it running with the gas engine but am sure that the
electric out performs that.
Range50 Miles (80 Kilometers)
EV Miles
Current:3,000 Miles (4,827 Kilometers)
Seating Capacity2 adults
Curb Weight1,650 Pounds (749 Kilograms)
Completed EV weight
Conversion TimeHave been slowly working on this for about 4 years - is now my
daily driver to work.
Conversion Cost$700 car
$1,600 motor
$1,975 Zilla controller
$425 motor adapter
$5,000 batteries
$800 BMS
$100 DC-DC
$400 Charger
4/6/08 Now that the motor is in the car and i have brakes that work, i decided to go for a spin
around the block. So i grabbed my jumper cables and the marine battery out of my boat..... I think
i could have walked faster but i still got a kick out of it.

5/14/08 It is starting to look liike a car! The fenders are on. The potbox is in and hooked to the
pedal.
I was able t make a tach sensor using a hall effect sensor from Digi-Key and some magnets. In
neutral with 12v my motor spins 1600RPM.
Last night i started buliding the rear battery box.

8/6/09 batteries are due to ship from china next week

10/10/09 Batteries have arrived, charger has been ordered. Car is primered and almost ready for
painT

9/1/10 After a long delay I have painted the Midget. All batteries and charger is in. This car is a
little rocket! I still need a few small parts for the car to finish assembly, but will soon be on the
road.

6/10/11 I now have temp tags on the car and have been driving to work for a week. To register as
an EV in CO I have to get a VIN verification, get the car weight, and bring all of my conversion
receipts to the DMV. The car has been preforming as well as expected except that the Zilla is
overheating and limiting my power for the last few miles of my trip from work. This week I will get
the water cooling hooked up to the controller. I am having to carefully monitor the end of charge
to not overcharge any of my batteries.

8/15/11 I have 500 ev miles on the car with no powertrain problems. Went to replace front brakes
and found entire front suspension is in bad shape. Car is down until suspension can be rebuilt.

5/17/12 I have recently installed a BMS to fully automate the charge cycle and keep my pack
safe. The MG now has about 3000 EV miles and has required no major maintence on any of the
EV components.
