| Owner | James Beyer |
|---|---|
| Owner's Other EVs | 500 Watt Electric Scooter 250 watt Electric Scooter 500 Watt bike |
| Location | London, England United Kingdom map |
| | |
| Vehicle | 2008 |
| Motor | HXT 63-74 200kv Brushless DC Voltage range 10-37v 200Kv Weight 790g 10mm shaft power 2880watts 100 Amp ESC |
| Controller | Turnigy Sentilon 100 Amp HV Bulletproof Speed Controller High voltage BESC BEC OPTO ver 3.1 2-12 Li-poly / 5-36NC E Sky servo adjuster to rc interface pwm controller |
| Batteries | 4 Venom 3600Nimh, 7.20 Volt, Nickel-Metal Hydride |
| System Voltage | 29 Volts |
| Charger | Pro-Peak Varipulse 2x AC/DC Delta Peak Fast Charger Charge Rate 200Mah to 3000Mah 4.8v-9.6v |
| Heater | Mother nature |
| Instrumentation | Whatt's up 100A 60v 6500watt lcd meter |
| Top Speed | 25 MPH (40 KPH) This is an approximation calculated by the gear ratio of 2.75:1 and the voltage and rpm of the motor that turns the wheel. The circumference of the wheel is 44 cm. |
| Acceleration | expecting 0 to 25 mph in about 3 seconds, but you would just get thrown off. So bout 6-8 seconds is reasonable |
| Range | 6 Miles ( 9 Kilometers) This is very dependent on the riders weight and weather conditions |
| Watt Hours/Mile | 207 Wh/Mile |
| Seating Capacity | 1 and maybe a second but they will have to be small |
| Curb Weight | 18 Pounds (8 Kilograms) I have weighed all of the components together and got 18lbs but this will probably change!!! |
| Tires | 265mm extra large solid official Micro scooter wheels with Abec bearings |
| Conversion Time | 50 hours drawing out diagrams on Solidworks 2008 and assembly time. |
| Conversion Cost | Quite a bit |
2008 Phoenix Scooter
“Brushless Hotrod”
Last Updated 10-02-2008
