evShop's 2004 Mirsubishi Mirage

Owner	Daniel Booth
Owner's Other EVs	1984 Mazda RX7 1992 Daihatsu Charade
Location	Perth, Western Australia Australia ^map
Web/Email	WebPage
Vehicle	2004 Mitsubishi Mirage
Motor	Netgain Impulse-9 Shunt Wound DC
Drivetrain	Manual
Controller	Curtis 1231C
Batteries	Thunder Sky LFP90AHA, 0.00 Volt, Lithium-Ion
System Voltage	144 Volts
Charger	Custom 15 Amp @ 240V
Heater	144 volt heater element, heating coolant to 75 degree Celsius. It is pumped through original heater core.
DC/DC Converter	Iota DLS-45 45 amp
Instrumentation	TBS Pro
Top Speed	85 MPH (136 KPH)
Range	50 Miles (80 Kilometers)
Seating Capacity	5 adults
Tires	standard
Conversion Time	3 months part time. With prefabrication of parts we should be able to complete the conversion within 2 weeks.
Conversion Cost	Completed cost with labour around $20,000 AUD
Additional Features	Power Steering and Air Con retained, by use of auxiliary motor. Safety lock outs to prevent vehicle movement whilst being charged. Rev limiter. All high voltage components when insulated and not accessible. Air bag system retained and functional.
This vehicle was made as a prototype for evaluation and promotion for the EVshop, to produce kits and provide low cost conversions to the public. Past licensing and engineering first time. Is being driven daily, with no problems.
