Controls500W Hub motor and double walled rim
OwnerDavid Wahl
LocationMadison, Wisconsin United States map
Vehicle1999 GIANT ATX 870
I bought the bike from a guy at work who
hadn't used it in a while. All it
needed was a little cleaning and
adjustment and it was good to go.
Motor Brushless DC
500W brushless hub motor in the front
wheel
DrivetrainFront: Direct drive
Rear: 21 speed, Shimano STX
Batteries12, 3.20 Volt, Lithium-Ion
12 10Ah LiFePO4 cells with BMS. Nice and
light, the whole pack weighs maybe 8
pounds.
System Voltage36 Volts
HeaterIf I get cold, I pedal harder.
InstrumentationSigma BC1606L Bike Computer
Watts Up Meter (WU100)




Top Speed20 MPH (32 KPH)
It will hit about 18-20 without pedaling
on smooth, level ground. Up hills it
drops down to around 15-16 unassisted.
AccelerationImpressive, I usually beat cars through
an intersection.
Range25 Miles (40 Kilometers)
25-40 miles with some pedaling is my
guess, although I've never actually
tested it.
Watt Hours/Mile13 Wh/Mile
With some pedaling I use about 110Wh on
the 8.9 mile ride to work.
EV Miles
Current:500 Miles (804 Kilometers)

    As of 8/4/2009
Seating Capacity1 adult
Tires26X1.75" Continental City Rides
Kept at about 50-55 psi, they are a nice smooth ride, although a little bumpy without any suspension.
Conversion Time3-4 hours
Conversion CostBike: 200
Battery: 370
Motor/controller: 325
Power meter: 53
Misc: ~50

All together around $1000
Additional FeaturesSwitched the front cantilever brakes for V-Brakes, much
better stopping power.
Riding an AWD bike is lots of fun in the snow.
