motoradapter platemotor and gearboxbaterie box
Ownerwubbert
Owner's Other EV1992 CityCom Mini-el city
LocationDeventer, Overijssel Netherlands map
Email email image
Vehicle1993 Daihatsu Blind Van
Motor Ziehl abegg 48V 3-phase 8KW 3-Phase AC
8kw @ 48VAC elevator motor.
running it on double voltage will give
16KW
ControllerZapi AC4 96V 500A
with regen braking
Batteries16 100AH UPS, 96.00 Volt, Lead-Acid, Gel
System Voltage96 Volts
ChargerZivan NG3
96V 16A
Heater150W 12v heater and seat heater
DC/DC Converter 96 --> 13,8V 40Amp
from an old Fiat Panda Elettra
Instrumentationoriginal speedometer and Xantrex battery
monitor
Top Speed45 MPH (72 KPH)
70km/h in 4th gear
Accelerationvery good! the motor has 180NM of torq
Range20 Miles (32 Kilometers)
I can only get 40 AH out of the bateries.
They are made to discharge with 10AH and I
do that 18 times
Watt Hours/Mile180 Wh/Mile
EV Miles
Start:12,120 Miles (19,501 Kilometers)
Current:13,700 Miles (22,043 Kilometers)
Total:1,580 Miles (2,542 Kilometers)
Seating Capacity2 adults
Curb Weight2,425 Pounds (1,102 Kilograms)
the bateries weight 800lbs!!
Tires145x12
Conversion Time3 months
This car I built for work/home traffic.
I charge at home and at my work.
I drive it for 40KM every day!!
