OwnerCarlos Hernandez
LocationSydney, New South Wales Australia map
Email email image
Vehicle1998 Yamaha FZR250 - 3HX2
With EXUP (EXhaust Ultimate Power). It (used
to) consist of a servo
motor driven valve which is fitted in the
exhaust system where the four pipes were join
into one under the original gearbox. Now I
have those servos to play with also for other
purposes obviously.
MotorAdvanced DC K91-4003 Series Wound DC
Nice 10 HP
ControllerCurtis
PWM,
Overheat, Undervoltage, Overvoltage,
Overcurrent, etc.. controls
Batteries48 LiFePo4, 0.00 Volt,
48 Cells (2 banks of 24 each).
72V and plenty of Amps.
System Voltage72 Volts
InstrumentationRPM, Volts, Amps
Top SpeedUnknown yet, once finished, I will let you know.
AccelerationUnknown yet, once finished, I will let you know.
RangeUnknown yet, once finished, I will let you know.
Watt Hours/MileUnknown yet, once finished, I will let you know.
Seating Capacity2 adults
Curb Weight0
Unknown yet, once finished, I will let you know.
TiresFactory set
Conversion TimeSo far, 8 months in evenings, weekends
Conversion CostSo far, around 10K
Additional FeaturesThis eBike will be unique.

ADC + Curtis + LiFePo4 Batts + CVT

The CVT will give the motor better response at the higher range
of RPMs

25-Oct-09 Can't believe my last post was 1 month ago!!

Progress: CVT has cover now, controller nicely under the seat now,
battery cells will go inside old 'petrol' tank, next week wiring
(at last!).

29-Sept-09 I started applying rust-converter to make sure the
original frame is, well... free of rust patches.

Also, I finally got the CVT and motor on the frame with the right
size belt, and beautifully in line...

About the on-board generator-charger, once it's in place (not at
stage1, since I been busy just with the mechanic parts for a while
now) will charge the single battery bank, at all times. Instead of
having 2 separate battery banks, I will have them all in single
one, 72V and plenty of juice (Amps).

5-Sept-09 Finally sprocket & bearings in the right place, there
was a mis-communication error between design and engineering :)
next week all will be on the frame!
I expect it to be street ready by November-09 !
