| Owner | Joseph Bartelt |
|---|---|
| Location | North Lake, Wisconsin United States map |
| | |
| Vehicle | hand built scooter |
| Motor | Permanent Magnet DC 4" x 6" |
| Drivetrain | 7.5 to 1 ratio #35 chain drive |
| Controller | 24 Volt PWM, over 36 Volt bypassed through starter relay home built |
| Batteries | 3, 12.00 Volt, Lead-Acid, Flooded marine deep cycle 34 Ah, third battery optional for extra boost |
| System Voltage | 36 Volts |
| Charger | 12 Volt 10 Amp automatic |
| Instrumentation | speedometer |
| Top Speed | 23 MPH (37 KPH) at 36 Volts, 16 MPH at 24 Volts |
| Range | 12 Miles (19 Kilometers) |
| Seating Capacity | 1 adult |
| Curb Weight | 60 Pounds (27 Kilograms) with two batteries, 75 pounds with three |
| Tires | 12" pneumatic plastic rims |
| unit folds up to fit in the trunk of my car. the frame is completely made of aluminum. has a motorcycle type twist throttle the seat was custom made and is held on with velcro. I drive this scooter almost every day to get the mail and it currently has over 400 miles logged on the speedometer. | |
Hand built Scooter
“Joe's Suicide Machine”
Last Updated 10-20-2000
